FEATURES:
Full automatic programmed operation.
Automatic alarm for overload or short of material.
Stainless steel hopper construction.
Main controller and hopper designed separated,to ensure safety and conveniet.
Separated filter installation, easy to remove pooling of powder.
Automation pump reverse system.
Specifications:
| Model |
KSAL-700G |
KsAL-800G |
KSAL-900G2 |
| Motor |
Type |
Carbon brusg |
induction |
induction |
| Specification |
1KW/1.3HP 1Ф |
1.1KW/1.5HP |
2.2KW/3HP 3Ф |
| Conveying capacity(kg/h) |
310 |
450 |
590 |
| Loading distance(m) |
4 |
4 |
5 |
| Static wind pressure(mm/H2O) |
1300 |
2100 |
2900 |
| Reservoir volume(L) |
6 |
6 |
12 |
| Conveying tube inner dim(mm) |
Ф38 |
Ф38 |
Ф38 |
| Specification of the attached hoses(mm) |
Ф38mm*4m 2pcs |
Ф38mm*4m 2pcs |
Ф38mm*5m 2pcs |
| Dimensions LxWxH(cm) |
Main frame |
37*30*56 |
42*38*64 |
50*40*72 |
| Hopper |
28*34*43 |
45*32*45 |
45*32*45 |
| Net weight(kg) |
Main frame |
14 |
47 |
66 |
| Hopper |
6 |
10 |
10 |
|
